Laboratories

This department has the following laboratories

1. CAD/CAM Laboratory

2. Dynamics Laboratory

3. Thermal Engineering Lab

4. Manufacturing Technology Lab I

5. Manufacturing Technology Lab II

6. Strength of Materials Lab

7. Fluid Mechanics and Machinery Lab

8. Metrology and measurements Lab

9. Heat and Mass Transfer Lab

10. Computer Aided Drafting and Modeling Lab

11. Mechatronics Lab

12. Engineering Practices Lab

List Of Equipments Available In The Laboratories

Name of the Laboratory	S.NO	Name of the Equipment
Engineering Practices Laboratory	1	Assorted components for plumbing consisting of metallic pipes, plastic pipes, flexible pipes, couplings, unions, Elbows, plugs and other fittings.
	2	Carpentry vice
	3	Standard woodworking tools
	4	Models of industrial trusses, door joints, furniture joints
	5	Power Tools like Rotary Hammer, Demolition Hammer Circular Saw, Planer, Hand Drilling Machine
	6	Arc welding transformer with cables and holders
	7	Welding booth with exhaust facility, Welding accessories like welding shield, chipping hammer, wire brush, Oxygen and acetylene gas cylinders, blow pipe and other welding outfit.
	8	Hearth furnace, anvil and smithy tools
	9	Moulding table, foundry tools
	10	Power Tool: Angle Grinder

Name of the Laboratory	S.NO	Name of the Equipment
Computer Aided Drafting and Modeling Laboratory	1	Pentium IV computer or better hardware, with suitable graphics facility
	2	Licensed software for Drafting and Modeling
	3	Laser Printer

Name of the Laboratory	S.NO	Name of the Equipment
Manufacturing Technology Laboratory – I	1	Centre Lathe with accessories
	2	Arc welding machine
	3	Gas welding machine
	4	Sheet metal work facility
	5	Sand moulding Facility
	6	Injection moulding Machine

Name of the Laboratory	S.NO	Name of the Equipment
Fluid Mechanics and Machinery Laboratory	1	Orifice meter
	2	Venturi meter
	3	Rotameter
	4	Pipe Flow analysis
	5	Centrifugal pump
	6	Reciprocating pump
	7	Gear pump
	8	Pelton wheel turbine
	9	Kaplan turbine

Name of the Laboratory	S.NO	Name of the Equipment
Strength of Materials Laboratory	1	Universal Tensile Testing machine with double shear attachment
	2	Torsion Testing Machine
	3	Impact Testing Machine
	4	Brinell Hardness Testing Machine
	5	Rockwell Hardness Testing Machine
	6	Spring Testing Machine
	7	Metallurgical Microscopes
	8	Muffle Furnace

Name of the Laboratory	S.NO	Name of the Equipment
Computer Aided Machine Drawing Laboratory	1	Computer Systems with Advanced graphics accelerator
	2	Laser Printer
	3	Software - recent versions of AutoCAD, SOLIDWORKS,SOLIDEDGE and PRO-E

Name of the Laboratory	S.NO	Name of the Equipment
Manufacturing Technology Laboratory II	1	Turret and Capstan Lathes
	2	Horizontal Milling Machine
	3	Vertical Milling Machine
	4	Surface Grinding Machine
	5	Cylindrical Grinding Machine
	6	Shaper
	7	Slotter
	8	Radial Drilling Machine
	9	Tool Dynamometer
	10	Gear Hobbing Machine
	11	Tool Makers Microscope

Name of the Laboratory	S.NO	Name of the Equipment
Thermal Engineering Laboratory – I	1	I.C Engine – 2 stroke and 4 stroke model
	2	Red Wood Viscometer
	3	Apparatus for Flash and Fire Point
	4	4-stroke Diesel Engine with mechanical loading
	5	4-stroke Diesel Engine with hydraulic loading.
	6	4-stroke Diesel Engine with electrical loading
	7	Multi-cylinder Petrol Engine
	8	Steam Boiler

Name of the Laboratory	S.NO	Name of the Equipment
Dynamics Laboratory	1	Cam analyzer.
	2	Motorised gyroscope
	3	Governor apparatus - Watt, Porter,Proell and Hartnell governors
	4	Whirling of shaft apparatus
	5	Dynamic balancing machine
	6	Static and dynamic balancing machine
	7	Vibrating table
	8	Gear Model
	9	Kinematic Models

Name of the Laboratory	S.NO	Name of the Equipment
Metrology and Measurements Laboratory	1	Micrometer
	2	Vernier Caliper, Vernier Height Gauge, Vernier depth Gauge
	3	Slip Gauge Set
	4	Gear Tooth Vernier
	5	Sine Bar
	6	Bevel Protractor
	7	Floating Carriage Micrometer
	8	Profile Projector / Tool Makers Microscope
	9	Mechanical and Pneumatic Comparator
	10	Temperature Measuring Setup
	11	Displacement Measuring Setup
	12	Force Measuring Setup
	13	Torque Measuring Setup

Name of the Laboratory	S.NO	Name of the Equipment
CAD/CAM Laboratory	1	Computer Server
	2	Computer nodes or systems (High end CPU with atleast 1 GB main memory) networked to the server
	3	Laser Printer
	4	Trainer CNC Lathe
	5	Trainer CNC milling
	6	CAD/CAM software (Pro-E )
	7	CAM Software (CNC Programming and tool path simulation for FANUC)

Name of the Laboratory	S.NO	Name of the Equipment
Thermal Engineering Laboratory II	1	Guarded plate apparatus
	2	Lagged pipe apparatus
	3	Natural convection-vertical cylinder apparatus
	4	Forced convection inside tube apparatus
	5	Pin-fin apparatus
	6	Stefan-Boltzmann apparatus
	7	Emissivity measurement apparatus
	8	Parallel/counter flow heat exchanger apparatus
	9	Single/two stage reciprocating air compressor
	10	Refrigeration test rig
	11	Air-conditioning test rig

Name of the Laboratory	S.NO	Name of the Equipment
Computer Aided Simulation and Analysis Laboratory	1	Analysis software suitable to computer Aided simulation & Analysis Lab with advanced professional facilities
	2	MATLAB
	3	Color Desk Jet Printer

Name of the Laboratory	S.NO	Name of the Equipment
Mechatronics Laboratory	1	Basic Pneumatic Trainer Kit with manual and electrical controls
	2	Basic Hydraulic Trainer Kit
	3	HYDROSIM & PNEUMOSIM software
	4	8051 – Microcontroller kit with stepper motor and drive circuit LABVIEW software
	5	LAB VIEW software with Sensors to measure Pressure, Flow rate, direction, speed, velocity and force
